3D Point Cloud

Your single source for a 3D view



A digital twin is only as good as the data that comprises it. To combat risk, industrial leaders enlist 3D data capture technology to maintain an accurate as-is condition of the asset as continuous change occurs throughout the asset and operations lifecycle.



AVEVA 3D Point Cloud enables surveyors, engineers and asset owners to bring point cloud data together and collaborate on a single data source. Information captured in this way can be shared and used by data stakeholders throughout the asset life cycle. They can access a reliable digital asset without having to physically visit the site with AVEVA 3D Point Cloud and create pinpoint accurate deliverables by integrating as-built data into 2D drawings and 3D models.



AVEVA Point Cloud Manager Server enables you to register, process and visualize point cloud data across the life cycle of your asset. Data can be imported from any device and exported downstream in a variety of CAD applications.



Features:

Validation and visualization

  • BubbleView™ – access a scanner’s eye view of your data. Make precise measurements, add intelligence.  HyperBubble™ – fly through BubbleViews meshed together into a 3D landscape
  • Solid Pointcloud™ – a low-hardware way of rendering point cloud data into visually solid surfaces. This allows user to understand an entire site on-screen at once, then dive down deeper into an area of interest
  • Access point cloud data from mobile devices. Take data offline when network connections are unavailable
  • Smart tools validate data automatically as you add to your dataset and check error values and use traffic light system for customized thresholds
  • Automatic Clash Detection against existing 3D models

Data management

  • Identify and focus on high value areas and hide unwanted data
  • Keep data alive by incrementally updating your dataset with new scans
  • Data is never gone forever – always retrievable
  • Offload storage and computational power to cloud services

Integrate CAD

  • Bring CAD objects into your point cloud dataset from compatible packages also finding project tie-ins to help drive engineering decisions
  • Semi-automatically create as-built 3D CAD models from as-built data
  • Model pipes and structural standards from the standards library
